Premium 100HP 4WD Tractor – Ideal Choice With AC Cabin For Farmers
| Lugar de origen | Porcelana |
| Nombre de la marca | BSM |
| Certificación | supply |
| Número de modelo | BTB1004 |
BTB1004 100HP 4WD Wheel Tractor
Product Introduction
The BTB1004 is a 100HP four-wheel drive wheel tractor built for heavy-duty agricultural operations, combining reliable power, stable performance, and user-friendly design. It is widely used for plowing, tilling, sowing, harvesting, transportation, and other farm work, making it the ideal choice for modern farms and agricultural contractors.
Key Parameters
| Parameter | Value |
|---|---|
| Model | BTB1004 |
| Horsepower | 100HP |
| Type | Wheel tractor |
| Driving method | 4WD |
| Gearbox | 12F + 12R |
| Wheelbase | 2020 mm |
| Front track | 1300 mm |
| Rear track | 1300–1500 mm |
| Minimum ground clearance | 380 mm |
| Tyres | 8.3-20 / 14.9-28 |
| Fuel tank | Side fuel tank |
| Net weight | 3450 kgs |
| Overall size (LWH) | 3900*1800*2770 mm |
Main Features
-
Strong & Stable Power System
Powered by a 100HP engine matched with a 12F+12R gearbox, providing abundant power and multiple speed options for different working conditions. The TB chassis ensures high strength, stability, and durability under heavy loads.
-
Excellent Passability & Adaptability
Standard 4WD system delivers strong traction and good performance in muddy, wet, and hilly fields.
- Minimum ground clearance: 380 mm
- Adjustable rear track (1300–1500 mm)
- Standard tyres: 8.3-20 (front) / 14.9-28 (rear)
The tractor offers great passability and field adaptability.
-
Efficient Working Performance
Equipped with one set of hydraulic output and a strong lifting system, ensuring stable and efficient operation of various agricultural implements. PTO speed: 540 / 760 r/min, widely compatible with rotavators, plows, harrows, seeders, trailers, and other tools.
-
Reliable Structure & Complete Configuration
- Side fuel tank for convenient refueling
- Safety rack for higher operation safety
- Counterweight: 8 pieces front & 2 pieces rear, improving stability and balance
- Standard canopy for sun and rain protection
- Net weight 3450 kgs provides stable and low-vibration working performance.
Advantages
- High 100HP power & fuel-efficient performance
- 4WD with strong traction and good passability
- 12F+12R gearbox for flexible speed selection
- Strong hydraulic lifting system & universal PTO
- Safe, durable, and comfortable for long-time work
- Suitable for large farms, planting bases, and various farmland operations
BTB1004 100HP 4WD wheel tractor is your reliable partner for efficient and modern agricultural production.
